RFI CDQ8195 6.5dBi Black Q-Fit® Cellular + CDQ5000 UHF Black Q-Fit® Antenna 98cm

RFI CDQ8195-B 6.5dBi 4G/LTE/5G Black Q-Fit® Antenna + RFI CDQ5000-B UHF 477MHz Black Q-Fit® Vehicle Bull Bar Antennas (Both 975mm high)

Key Features
(SKU:  CDQ8195+5000-BTPK)

• RFI CDQ8195-B 5G LTE Antenna Black
  • 698-960MHz, 1710-2170MHz, 2300-2700MHz & 5G LTE 3400-3800MHz
  • 4.5 - 6.5dBi Gain
  • 975mm (Removable Whip)
  • Heavy Duty, Rugged design
  • Pre-terminated SMA connector


• RFI CDQ5000-B Antenna Black
  • 477MHz
  • 5dBi Gain
  • Length 975mm
  • Black Radome high impact fibreglass construction
  • Ground Independent



OVERVIEW

The CDQ8195 5G LTE antenna not only covers the 4G LTE bands (698-960MHz, 1710-2170MHz, and 2300-2700MHz) but now the new 5G LTE band (3400-3800MHz).

The outstanding performance of the CDQ8100 series lies in the use of the patented Meander™ radiating elements. These Meander™ circuits are coupled together to deliver extraordinary consistency in gain, coverage pattern, and bandwidth. The result is a unique antenna able to operate across all mobile phone networks globally, housed in one unit.

The CDQ5000 antenna is based on RFI’s successful CD5000 antenna and designed to the same revolutionary performance. The secret to this extraordinary performance lies in the use of a unique PCB radiator. The patented Meander™ circuit delivers exceptional consistency in gain and pattern.

The CDQ8195 and CDQ5000 employs the new Q-Fit® removable whip system for fast and simple whip removal when entering low height areas such as car parks or when using car washes. This antennas are supplied with a waterproof cap to ensure no water/dust ingress into the antenna connection when the whip is removed. With a heavy duty integrated spring, the CDQ8195 & CDQ5000 can be installed on a number of mounting brackets and are ideal for installations in commercial vehicles, four wheel drives and trucks.

RFI (RF Industries) - THE BRAND

RFI was established way back in 1979. Fast forward to today and RFI manufacture antenna products in Bayswater, Vic, they employ over 250 people to handle R&D, Design and distribution of their products to over 150 countries across the globe.

RFI have a strong brand reputation and their antennas are unrivalled in the industry for quality and performance.

Didn't find what you wanted? Browse all UHF + Cellular antennas

TECH SPECS

RFI CDQ8195-B 5G LTE Cellular Antenna

GENERAL
Frequency Band
698-960MHz, 1710-2170MHz, 2300-2700MHz & 5G LTE 3400-3800MHz

dBi (Gain)
4.5 - 6.5dBi

Ground Dependance
Ground Independent

Construction Type
Mobile phone antenna, black fibreglass radome, heavy duty spring, 5m of low-loss coaxial cable

Height/ Length
975 mm

Cable and Connector
5m RG58 (9006) low loss cable terminated with SMA male connector

RFI CDQ5000-B UHF CB Antenna

GENERAL
Frequency Band
477 MhZ

dBi (Gain)
5dBi

Ground Dependance
Ground Independent

Construction Type
UHF antenna, black fibreglass radome, heavy duty spring, 5m of low-loss coaxial cable

Height/Length
975 mm

Cable and Connector
5m of 9006 low loss cable terminated with FME female connector and UHF adaptor

WHATS IN THE BOX

The RFI CDQ8195+5000-BTPK pack is made up of:

RFI CDQ8195-B Antenna Assembly

• 6.5dBi Antenna Whip
• Heavy Duty Spring Base with 5m Lead Assembly
• Integrated 5m RG58 (9006) low loss cable terminated with SMA male connector

RFI CDQ5000-B Antenna Assembly

• M477Mhz UHF/CB Radio band Antenna Whip
• Heavy Duty Spring Base with 5m Lead Assembly
• 5m of 9006 low loss cable terminated with FME female connector and UHF adaptor

WARRANTY - 1 YEAR
